Powerful Main Fog Horn
The Explosion-proof Powerful Fog Horn is designed and manufactured in strict accordance with standards, fully compliant with SY 6985-2014: Sound and Light Aids to Navigation for Offshore Oil Facilities.
The sound wave reflector, patented by our company, enables 360° omni-directional sound guidance, ensuring that the signal can be clearly heard in all directions.
Featuring a unique explosion-proof design, the product has a protection rating of IP66. The housing is made of 316L stainless steel or copper-free aluminum with glass fiber reinforced polyester, suitable for an operating temperature range of -40°C to +50°C, providing excellent resistance against harsh marine environments and corrosion.
The auxiliary fog horn is equipped with 1 sound-emitting unit, ensuring reliable performance.
Transmission Range: 2 nautical miles
Material: 316L stainless steel, copper-free aluminum + glass fiber reinforced polyester
Sound Pressure Level: > 140 dB
Technical Specifications
| Explosion-proof Marking: | Ex d IIC T6 Gb; Ex tD A21 IP66 T80°C |
| Rated Voltage: | DC24V / AC220V |
| Corrosion Protection Grade: | WF2 |
| Operating Frequency: | 900 Hz |
| Transmission Range: | Main horn > 2 nautical miles; |
| Product Weight: | Main horn: approx. 165 kg / 175 kg / 215 kg |
| Dimensions:Main horn: | 561 mm × 561 mm × 1900 mm |
| Material: | 316L stainless steel, copper-free aluminum + glass fiber reinforced polyester |
| Explosion-proof Application: | Suitable for gas explosive environments |
| Sound Pressure Level: | Main horn > 140 dB |
| System Safety: | Automatic activation of the auxiliary horn in case of main horn failure |
