NT211 Explosion-proof gas monitoring camera
Long-distance real-time detection of specific gas concentrations in the air
The leakage of methane gas is monitored in real time at a distance by adopting a non-contact method. It has high sensitivity and fast response speed, and can react before the diffusion of methane gas gets out of control.The PTZ supports 360° horizontal rotation and -90° to +90° vertical rotation, providing all-weather, all-time and all-round online monitoring of methane leakage. It can meet the monitoring requirements in different application scenarios.
Technical specification
| Explosion-proof certification | Ex-mark： | Ex db ⅡC T6 Gb |
| General specification | Rated voltage: | AC220V |
| Weight | 30kg | |
| Product materia： | 316L | |
| IP rating： | IP66/IP68 | |
| Internal space dimensions： | Length, width and height:463×303×411mm | |
| Ambient temperature： | Temperature： -40℃~+70℃ Humidity：≤95%RH（No condensation） | |
| Methane monitoring specification | Measurement range： | 0-100000ppm.m |
| Detection distance： | Farthest80m/120m/160m（Optional） | |
| Camera specification | Effective pixel： | 4 million |
| Sensor type： | Progressive Scan CMOS | |
| Resolution： | 2560×1440 | |
| Signal-to-noise ratio： | ＞52dB | |
| PTZ specification | Horizontal and vertical range： | Horizontal360°，vertical-90°~ +90° |
| Vertical velocity： | 0.1°- 40°/s | |
| Horizontal velocity： | 0.1°- 40°/s | |
| Number of preset positions： | 255 | |
| Automatic cruise： | Support | |
| System integration | Alarm output： | Optional explosion-proof sound and light alarm |
| Alarm linkage： | Support alarm upload to the background management software | |
| Network interface： | RJ45 network port, supporting 10M/100M network data |
Product dimension diagram
